9-3/4" Spiral Drill Pipe of Drill String Tools

Price:	10.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Shaanxi, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: KINGWELL 9-3/4" Drill Pipe ...

Production Capacity: 1000 set per month

Delivery Date: 30 days after received adva...

Standard: API SPEC 7-1

Model: 9-3/4"

Export Percentage: 95%

Brand Name: KW

Means of Transport: Ocean,Land,Air

Packing: bundling or loose

Material: AISI 4145 H Modified Alloy ...

Applicantion: offshore well drilling

MOQ: 2 Sets

Supply ability: 1000 sets per month

1.Standard: API Spec 7-1
2.Material: AISI 4145 H Modified Alloy Steel
3.Export Percentage: 95%
4.Supply Ability: 1000 sets per month
5.MOQ: 2 set

9-3/4"Spiral Drill Pipe of Drill String Tools

Specification:
1.Standard: API Spec 7-1

2.Material: AISI 4145 H Modified Alloy Steel

3.Export Percentage: 95%

4.Supply Ability: 1000 sets per month
5. Main Market: Middle East, North America, Europe
6. Delivery time: 10 days in stock, 30 days after advance payment
7. Payment terms: T/T, L/C
8. original: China

Detailed pictures for goods,

9-3/4Spiral Drill Pipe of Drill String Tools

Thechnical Parameter

Drill Collar Model	D		d		L(mm)	DF(mm)	Bending Strength ratio	Drill Collar Nominal size
Drill Collar Model	mm	In	mm	in	L(mm)	DF(mm)	Bending Strength ratio	Drill Collar Nominal size
QW-DC3-1/8	79.4	3-1/8	31.8	1-1/2	9,150	76.2	2.57:1	NC23-31
QW-DC 3-1/2	88.9	3-1/2	38.1	1-1/2	9,150	82.9	2.42:1	NC26-35(2-3/8IF)
QW-DC 4-1/8	104.8	4-1/8	50.8	2	9,150	100.4	2.43:1	NC31-41(2-7/8IF)
QW-DC 4-3/4	120.7	4-3/4	50.8	2	9,150	114.7	2.58:1	NC35-47
QW-DC 5	127	5	57.2	2-1/4	9,150	121	2.38:1	NC38-50(3-1/2IF)
QW-DC 6A	152.4	6	57.2	2-1/4	9,150/9,450	144.5	2.49:1	NC44-60
QW-DC 6B	152.4	6	71.4	2-13/16	9,150/9450	144.5	2.84:1	NC44-60
QW-DC 6-1/4A	158.8	6-1/4	57.2	2-1/4	9,150/9,450	149.2	2.91:1	NC44-62
QW-DC 6-1/4B	158.8	6-1/4	71.4	2-13/16	9,150/9,450	150	2.63:1	NC46-62(4IF)
QW-DC 6-1/2A	165.1	6-1/2	57.2	2-1/4	9,150/9,450	154.8	2.76:1	NC46-65(4IF)
QW-DC 6-1/2B	165.1	6-1/2	71.4	2-13/16	9,150/9,450	154.8	3.05:1	NC46-65(4IF)
QW-DC 6-3/4A	171.4	6-3/4	57.2	2-1/4	9,150/9,450	159.5	3.18:1	NC46-67(4IF)
QW-DC 6-3/4B	171.4	6-3/4	71.4	2-13/16	9,150/9,450	159.5	2.37:1	NC50-67(4-1/2IF)
QW-DC 7A	177.8	7	57.2	2-1/4	9,150/9,450	164.7	2.54:1	NC50-70(4-1/2IF)
QW-DC 7B	177.8	7	71.4	2-13/16	9,150/9,450	164.7	2.73:1	NC50-70(4-1/2IF)
QW-DC 7-1/4	184.2	7-1/4	71.4	2-13/16	9,150/9,450	169.5	3.12:1	NC50-72(4-1/2IF)
QW-DC 7-3/4	196.8	7-3/4	71.4	2-13/16	9,150/9,450	185.3	2.70:1	NC56-77
QW-DC 8	203.2	8	71.4	2-13/16	9,150/9,450	190.1	3.02:1	NC56-80
QW-DC 8-1/4	209.6	8-1/4	71.4	2-13/16	9,150/9,450	195.7	2.93:1	6-5/8REG
QW-DC 9	228.6	9	71.4	2-13/16	9,150/9,450	212.7	3.17:1	NC61-90
QW-DC 9-1/2	241.3	9-1/2	76.2	3	9,150/9,450	223.8	2.81:1	7-5/8REG
QW-DC 9-3/4	247.6	9-3/4	76.2	3	9,150/9,450	232.6	2.57:1	NC70-97
QW-DC 10	254	10	76.2	3	9,150/9,450	237.3	2.81:1	NC70-100
QW-DC 11	279.4	11	76.2	3	9,150/9,450	266.7	2.84:1	8-5/8 REG

About Quality: All the products with API, low price are not -API, cannot be exported.

About Warranty: Warranty period is 1 year after installation.
About Payment: 30% of the advance payments, delivery time, please pay 70%.

About Ttechnical Documents:I submit the following accompanying technical information in English,

A: Test Report in accordance with the appropriate API or national test standards outline

B. Commerial Invoice

C: Original copy of quality certificate

D: Packing List

E: The chemical element ,Mechanical properties.

About Service:

We believe in Customer delight, achieved by the supply of Quality Products & Services and Continual Improvement in our Manufacturing Processes for timely delivery at competitive prices. We work in a professional, competitive, and cost-effective manner consistent with the Customer requirement.
